MPR 1000/15 Gas engine

Trailer fire pump

Characteristics

  • Flowrate : 1000 litres/minute
  • Pressure : 10 to 15 bars
  • Height : 3m
  • Dimensions : Length: 3.200m / Width: 1.400m / Height: 1.390m
  • Service weight : 750kg

Specific features

PUMP

HAKA pumps – Type GB 60/15 AE

  • Single-cell centrifugal pumps.
  • Suction : 1xND100 fitted with a 1/2 AR coupling with filter + plug and bead chain.
  • Discharge : 2 to 5 mushroom valves or ¼ turn valves fitted with ½ DSP couplings ND65 and/or ND100 with plugs and bead chains.
  • Primer : fitted with an electric motor and a rotary vane vacuum pump, designed to operate without water and oil.
  • Option : water ring primer.

MOTORISATION

PEUGEOT engine - Type DV6 TD

  • Electronic injection.
  • Power : 68 kw at 6000 rpm - 1560 cm3.
  • Cooling : self-contained closed-cycle, with a radiator fitted with two electric fans.
  • Electronic ignition system – Battery main switch, emergency stop push-button.
  • Stainless steel gas tank – autonomy 2 hrs.
